1.偽裝網面顏色及拼花迷彩圖案：涂層顏色與標準樣板一致，顏色參數符合國軍標GJB798-1990中規定的標準，允許的色差Eab不大于3。拼花迷彩圖案分布符合國軍標GJB4004-2000規定的要求。

1. Camouflage mesh color and mosaic camouflage pattern: The coating color is consistent with the standard template, and the color parameters comply with the standards specified in the national military standard GJB798-1990. The allowable color difference Eab is not more than 3. The distribution of mosaic camouflage patterns meets the requirements of the national military standard GJB4004-2000.

2. 近紅外偽裝性能：所有偽裝網網面涂層綠色在0.4μm-1.2μm的光譜發射率均滿足標準葉綠素反射曲線要求。

2. Near infrared camouflage performance: All camouflage mesh surface coatings have a green color of 0.4 μ M-1.2 μ The spectral emissivity of m meets the requirements of the standard chlorophyll reflection curve.

特別說明：

Special note:

現實自然界中的綠色植被低的反射率都在0.5即50%以上，高反射率能達到0.85即85%，由于顏色深淺差異、陽面背陰的差異、稀疏茂盛的差異等等，造就了真實植被的近紅外反射率不是統一恒定的，而是具有不同差異的，從而形成深淺不一的階梯斑塊反射效果。

The lowest reflectivity of green vegetation in the natural world is 0.5 to 50% or above, and the highest reflectivity can reach 0.85 to 85%. Due to differences in color depth, shade on the sunny side, sparse and lush differences, etc., the near-infrared reflectivity of real vegetation is not uniform and constant, but has different differences, forming a stepped patch reflection effect of varying depths.

然而要達到深淺不一斑塊的近紅外反射率的工藝不是一般廠家能做到的，一般廠家所號稱的近紅外反射率只能做到高0.5即50%，而且只能做到整體都是統一的0.5反射率，再高于0.5的反射率是做不到的，做到反射率高低不同的斑塊效果那就更別提了。

However, the process of achieving near-infrared reflectance with different depths and depths of patches is not something that ordinary manufacturers can achieve. The so-called near-infrared reflectance of most manufacturers can only reach a maximum of 0.5 or 50%, and can only achieve a unified overall reflectance of 0.5. Reflectivity higher than 0.5 cannot be achieved, and achieving different patch effects with different reflectivity levels is not enough.

因此能稱為軍用級別的近紅外偽裝性能的偽裝網產品請認準2個指標：一個是反射率必須是大于0.5而不是小于等于0.5；另一個就是還能做到高低反射不同的斑塊效果。

Therefore, for camouflage net products that can be called military grade near-infrared camouflage performance, please identify two indicators: one is that the reflectivity must be greater than 0.5 rather than less than or equal to 0.5; Another is that it can also achieve different plaque effects with high and low reflections.

3. 中遠（熱）紅外偽裝性能：在8μm-14μm波段內實現目標熱圖與環境熱圖部分融合，與背景的平均輻射溫差在±4℃，具有明顯的熱隔絕效果。

3. COSCO (thermal) infrared camouflage performance: at 8 μ M-14 μ The fusion of the target heat map and the environmental heat map is achieved within the m-band, with an average radiation temperature difference of ± 4 ℃ from the background, which has a significant thermal isolation effect.

4. 雷達偽裝性能：經偽裝網偽裝后徑向、緯向雷達透射率的平均值為10%-30%，具有明顯的雷達反射衰減效果，在3厘米、8毫米、3毫米雷達波段范圍內各波段雷達波平均衰減10dB以上。

4. Radar camouflage performance: After being camouflaged by a camouflage net, the average radial and latitudinal radar transmittance is 10% -30%, with a significant radar reflection attenuation effect. The average attenuation of radar waves in each band is more than 10dB within the range of 3cm, 8mm, and 3mm radar bands.

5. 阻燃性：離火續燃時間≤5秒。

5. Flame retardancy: The ignition time after ignition is ≤ 5 seconds.

6. 色牢度：日曬色牢度：3-4級以上（印花）4-5級以上（涂層）；干磨色牢度：2-3級以上。

6. Color fastness: Sun fastness: 3-4 or above (printing) 4-5 or above (coating); Dry grinding color fastness: 2-3 levels or above.

7. 防腐防霉性能：達到國軍標GJB150.10-1986標準中的1級要求。

7. Anti corrosion and anti mold performance: Meet the level 1 requirements of the national military standard GJB150.10-1986.

更多的關于專業偽裝網的問題或者詳細的內容，請進入我們公司的網站：http://xucuo.cn網站中會有很多的內容僅供參考。

For more questions or detailed information about professional camouflage websites, please visit our company's website: http://xucuo.cn There will be a lot of content on the website for reference only.
